- A variable seals can choose to fit different temperature (80℃,100℃,180℃)
- Double acting/single acting [N.O] / [N.C.] can choose
- Compact body design allows for more installation positions
- Air control operated to fit flammable working environment
- The structure is simple and easy to maintain
- working pressure range in 0-1.0 Mpa (0 -145 Psi)
- The flow rate is larger than the Q22HD series
Pneumatic valve is a significant element in the fluid control system. From householders' to aerospace, pharmaceuticals, automobiles industries; from liquid to gas, they are all aspiring durable,reliable, ingenious on solenoid valve. Pneumatic valves have advantages in safe and reliable concept when compared with solenoid valve. In flammable and explosive working environment, electric force is always not a good choice. And under long-term high temperature environment, heat dissipation from the coils can be a problem, and it will shorten the life-time of the valve. So that pneumatic control valve could be a better option for above industries to bring a more secure and reliable solution.
Product Parameters
Category | 2/2 ways |
Way of action | air control |
Series | 2Q |
Body Material | Brass |
Way to control | pneuamtic valve |
Pressure resistance | 0-1.0 Mpa |
Sealing material | PTFE |
Temperature | -5 ~100 ℃ |
Caliber range | 1/4 - 2“ |
Normally open normally closed | N.C. |
Wiring | Air control |
